Description

EONIC Pulse Residential SDO

EONIC Pulse is a clean, modern residential sectional door opener designed and built in Australia. It focuses on quiet movement, dependable safety and simple daily control for family homes.

Key features

• Australian made residential sectional door opener
• 1000N peak pull force
• Whisper-quiet DC motor operation
• EON+ Advanced Rolling Code Technology
• EON+ Auto Reverse safety protection
• Optional battery backup and smart accessories available separately

Technical specifications

• Model: EONIC Pulse Residential SDO
• Warranty: 8 Years
• Maximum peak pull force: 1000N
• Maximum door area: 15m²
• Maximum door weight: 180kg
• Maximum lift balanced door: 20kg (200N)
• Maximum door height: 3.5m
• Drive mechanism: C-Rail with Belt Drive
• Operating speed: 121mm per second
• LED courtesy light: 24V / 138 pcs LEDs
• Input voltage: 220-240VAC, 50-60Hz
• Radio frequency: 433.92 MHz with EON+ Advanced Rolling Code Technology
• Code storage capacity: 64 memory registers
• Surge protection: EON+ surge and thermal overload protection
• Working temperature: -20°C to +45°C
• Ingress protection: IP30
• Fire Integration (FIP): Not compatible
