EONIC Royale Light Commercial SDO

EONIC Royale is built for larger, heavier sectional doors where extra strength and refined operation are needed. It pairs a 1500N motor with a heavy-duty aluminium rail and smooth belt drive for premium residential or light commercial use.

Key features

• Australian made light commercial sectional door opener
• 1500N peak pull force
• Heavy Duty Aluminium Rail with Belt Drive
• EON+ Advanced Rolling Code Technology
• EON+ Auto Reverse safety protection
• Fire Integration (FIP) compatible
• Optional battery backup and smart accessories available separately

Technical specifications

• Model: EONIC Royale Light Commercial SDO
• Warranty: 10 Years residential use or 25,000 cycles; 2 Years light commercial use or 20,000 cycles
• Maximum peak pull force: 1500N
• Maximum door area: 25m²
• Maximum door weight: 320kg
• Maximum lift balanced door: 20kg (200N)
• Maximum door height: 3.5m
• Drive mechanism: Heavy Duty Aluminium Rail with Belt Drive
• Operating speed: 148mm per second
• LED courtesy light: 24V / 138 pcs LEDs
• Input voltage: 220-240VAC, 50-60Hz
• Radio frequency: 433.92 MHz with EON+ Advanced Rolling Code Technology
• Code storage capacity: 64 memory registers
• Surge protection: EON+ surge and thermal overload protection
• Working temperature: -20°C to +45°C
• Ingress protection: IP30
• Fire Integration (FIP): Compatible
